| Place of Origin: | China |
| 브랜드 이름: | VEOLIA |
| 인증: | CE |
| Model Number: | Veolia EDI Modules E-Cell MK-3 |
| Document: | Veolia EDI catalog.pdf |
| Minimum Order Quantity: | 1 pc |
|---|---|
| 가격: | 협상 가능 |
| Packaging Details: | standard export packing |
| Delivery Time: | 5- 8 work days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 60000 Units per Month |
| MK-3 Maximum water production (m3 /hr): | 4.5 | MK-3 Minimum water production (m3 /hr): | 1.6 |
|---|---|---|---|
| MK-3 Recovery: | up to 96% | MK-3 Shipping Weight of this stack: | 100 kg (220 lbs) |
| MK-3 Hardness (ppm as CaCO3 ): | <1.0 | Sodium of this stack: | ≤ 3 ppb |
| Boron of this stack: | As low as 0.08 ppb | pH Range: | 4 to 11 |
| Color: | ≤ 5 APHA | Resistivity: | ≥ 16 MOhm-cm |
| Module Application: | Industrial High Purity Water Preparation | ||
| 강조하다: | Veolia MK-3 EDI Stack,EDI Stack for semiconductor water,Ultra pure water EDI module |
||
| Maximum Water Production | 4.5 m³/hr |
| Minimum Water Production | 1.6 m³/hr |
| Recovery Rate | Up to 96% |
| Shipping Weight | 100 kg (220 lbs) |
| Hardness (as CaCO₃) | <1.0 ppm |
| Sodium Content | ≤ 3 ppb |
| Boron Content | As low as 0.08 ppb |
| pH Range | 4 to 11 |
| Color | ≤ 5 APHA |
| Resistivity | ≥ 16 MΩ-cm |
| Application | Industrial High Purity Water Preparation |
| Parameter | Value |
|---|---|
| Nominal Flow | 3.4 m³/h (15 gpm) |
| Flow Rate Range | 1.7 - 4.5 m³/h (7.0 - 20 gpm) |
| Dimensions (W x H x D) | 30 cm x 61 cm x 54 cm (12" x 24" x 22") |
| Resistivity | ≥ 16 MΩ-cm |
| Sodium Removal | ≥ 99.9% |
| Silica Removal | Up to 99% |
| Boron Removal | Up to 96% |
| Operating Voltage | 0-300 VDC |
| Operating Amperage | 0-5.2 ADC |
| Inlet Pressure | ≤ 6.9 bar (100 psi) |
